PCA9685 16 Channel 12-Bit PWM Servo Driver Module

Name: PCA9685 16 Channel 12-Bit PWM Servo Driver Module
Brand: R and D Control Systems
Price: 1099.0 INR
Availability: InStock

Price 1099.0 INR/ Piece

Get a Price/Quote

MOQ : 5000 Pieces

PCA9685 16 Channel 12-Bit PWM Servo Driver Module Specification

Hole Size
0.30 mm (minimum) Millimeter (mm)

Min. Line Spacing
6 mil (0.15 mm) Millimeter (mm)

Impedance
50 Ohm (ohm)

Voltage Endurance
1500 V AC / 1 min Volt (V)

Insulation Resistance
Standard

Min. Line Width
6 mil (0.15 mm) Millimeter (mm)

Silkscreen
White

Test
Flying Probe Test

Soldermask
Green

Flame Resistance Level
UL94-V0

Product Type
PCB

Power Rating
N/A

Base Material
FR4

Surface Finish
Lead Free

Copper Thickness
1 oz (35 m) Micrometers (um)

Board Thickness
1.6 mm Millimeter (mm)

Color
Green

Panel Size
Single PCB

Sensor Switch
N/A

Rated Voltage
250 V AC Volt (V)

Usage & Applications
Industrial Electronics

Electrical Components
No

Cable Type
N/A

Operating Temperature
-40 C to +85 C Celsius (oC)

Warranty
N/A

Phase
Single Phase

Display Type
N/A

Conductor
Copper

Rated Current
1 A Microampere (A)

Features
High Reliability, RoHS Compliant

Frequency
50/60 Hz Hertz (HZ)

Material
FR-4

PCA9685 16 Channel 12-Bit PWM Servo Driver Module Trade Information

Minimum Order Quantity
5000 Pieces

Delivery Time
3 Days

About PCA9685 16 Channel 12-Bit PWM Servo Driver Module

Product Description

The PCA9685 16-Channel 12-Bit PWM Servo Driver Module is a compact and reliable I2C-based PWM controller designed for controlling multiple servo motors, LEDs, and other PWM-operated devices with high precision. Built around the PCA9685 controller IC, the module provides 16 independent PWM output channels with 12-bit (4096-step) resolution, enabling smooth and accurate control while reducing the processing load on the host microcontroller. It supports a programmable PWM frequency (approximately 24 Hz to 1526 Hz) and allows multiple boards to be connected on a single I2C bus for large-scale projects.
